| electrical feed 400 V, 3 phases, 50/60Hz or 230 V, 3 phases, 50/60Hz
|
| display LCD touch screen 5" with buttons |
| programmable control system (80 programs with maximal 100 cutting
steps in each of them) |
| language versions availability |
| cut counter |
| lockable main switch |
| digital cut dimensions setting and monitoring |
| optical and mechanical cut line indication |
| even and uneven repeating |
| semiautomatic cutting |
| programming by cutting |
| manual cuts dimension setting |
| clamping without cutting |
| programmable clamping without cutting |
| metric measurement system |
| time limited two-hand cut release |
| mechanical protection of the knife cut repeating |
| automatic shielding of knife by the clamp in any position |
| table with air cushion-off/on/automatic |
| ground finish of main table |
| lighting of the table work area |
| integrated calculator with data transfer |
| program protection against deletion |
| automatic indication of the maintenance period according to the cuts
reached |
| mechanical protection against overloading (tear-off screw) |
| mechanical replacement of the knife |
| false clamp plate (attachable from the front) |
| safety infrared light barier |
| continuous checking of the knife movement |
| failure diagnostics and error records |
| complete tools set |
| hydraulic camping |
| manual clamping pressure adjustment for cuuting of various materials
|
| knife replacement from the front side of the machine |
| HSS (High Speed Steel) knife - 1 pc mounted on the machine and 1 pc in
standard accessories |
| 5 pcs of cutting sticks, 2 pcs of bulbs |
| wooden piller MAXIMA |
| CE European Certificate |
| GOST Certificate |
| instructions manual |
|
memory capacity for entering and storage of 80 programs
with 100 cutting steps in each of them |
|
language versions in the control system (Czech, English,
German, Russian, Hungarian, Polish, French, Spanish ) |
|
software update |
|
remote communication with the machine by means of GSM
modem |
|
current machine status checking and that of reporting by
SMS |
|
even and uneven repeating |
|
clamping without cutting |
|
programmable clamping without cutting |
Cutting width ( mm ) |
1150 |
Knife movement time per cycle ( s ) |
1,5 |
Front table length ( mm ) |
710 |
Max. backgauge distance from cut line ( mm ) |
1190 |
Table height from the base ( mm ) |
900 |
Clamp with false clamp plate opening ( mm ) |
125 |
Clamp without false clamp plate opening ( mm ) |
130 |
Min. end waste - manual / power drive without false
clamp plate ( mm ) |
25/30 |
Maximum pre - clamping pressure by pedal ( N ) |
300 |
Clamp pressure ( N ) |
2000 - 39 000 |
Maximum backgauge speed ( mm.s-1 ) |
190 |
Job storage in memory period |
7 year |
Displayed backgauge position accuracy reading ( mm ) |
0,01 |
Total power input |
3×400 V/5,5 kW |
Length / width / height ( mm ) |
2663×2820×1565 |
Net weight ( Kg ) |
3250 |
Gross weight ( Kg ) |
3850 |
Dimension of crate ( mm ) |
|
